Dynaflow Inc. has several testing facilities for material erosion studies. These include:

  • Two test units for ASTM G32 - Cavitation Erosion testing using two 20 kHz vibratory
  • ultrasonic horns test units
  • ASTM G73 liquid impingement erosion testing:  750 ft/s impact at a rate of 28,000 impacts per minute, whirling arm facility (up to).
  • ASTM G76 Test Method for Conducting Erosion Tests by Solid Particle Impigment using Gas Jets.
  • Jet Erosion Testing: Several DynaJets® cavitating jet facilities enabling jet pressures from a few psi to 40,000 psi and flow rates from 1 gpm to 70 gpm.
  • ASTM G134 - Erosion by Cavitating Liquid Jets Testing:  A standard loop for the erosion of solid materials by cavitating liquid jets.
  • Droplet Impact Erosion: Testing using DynaJets® cavitating jets for droplet erosion testing.
  • A Split Hopkinson Pressure Bar (SHPB) : For the measurement of the high strain rates properties of materials.
  • Analytical Balances (2) with an accuracy of 0.1 mg.
  • Depth Gauges (2) with accuracy of 10-3 inch.
  • Metallurgical Microscope with image capture (Motic).
  • A Profilometer
  • Lapping Machine (South Bay).
  • Heat treating ovens

ASTM G73,the rotating disk liquid impact test apparatus

ASTM G32, ultrasonic or vibratory cavitation erosion test setup

Split Hopkinson Pressure Bar

Split Hopkinson Pressure Bar used to measure properties at high strain rates in the thousands of in/in/sec which can differ by an order of magnitude from those for quasi static loading.

Split Hopkinson Pressure Bar
